Details
Product Type
MEP
Type
SHARK 330 CNC FE
Description
MEP 330 Cnc Band Saw
.CNC Technology:
– Computer numerical control (CNC) that allows complete automation of the cutting process.
– Intuitive programming that facilitates the configuration and adjustment of cutting parameters, ensuring precision and repeatability.
. Automatic Feeding System:
– Automatic workpiece feeding with precise advance and retreat adjustments.
– Adjustable band guides that ensure accurate cuts and extend the life of the band saw.
.Cooling System:
– Efficient cooling system that keeps the cutting belt and workpiece at ideal temperatures, reducing wear and increasing cutting efficiency.
.Security:
– Integrated safety equipment, such as operator protections and emergency stop systems.
– Sensors that monitor the functioning of the machine and ensure safety during operation.
Technical specifications:
– 90° cut: Approximately 330 mm (round) / 330 x 330 mm (square) / 330 x 330 mm (rectangular)
– Cut at 45°: Approximately 270 mm (round) / 270 x 270 mm (square) / 270 x 270 mm (rectangular)
– Tape Speed: Adjustable between 20 and 100 m/min.
– Tape Dimensions: Approximately 4100 x 34 x 1.1 mm.
– Main Motor: Approximately 3.0 kW.
Approximate dimensions: 2000 x 1700 x 1800 mm
Weight: 1500 kg
Additional mandatory dismantling & loading on truck cost of: 200€
.CNC Technology:
– Computer numerical control (CNC) that allows complete automation of the cutting process.
– Intuitive programming that facilitates the configuration and adjustment of cutting parameters, ensuring precision and repeatability.
. Automatic Feeding System:
– Automatic workpiece feeding with precise advance and retreat adjustments.
– Adjustable band guides that ensure accurate cuts and extend the life of the band saw.
.Cooling System:
– Efficient cooling system that keeps the cutting belt and workpiece at ideal temperatures, reducing wear and increasing cutting efficiency.
.Security:
– Integrated safety equipment, such as operator protections and emergency stop systems.
– Sensors that monitor the functioning of the machine and ensure safety during operation.
Technical specifications:
– 90° cut: Approximately 330 mm (round) / 330 x 330 mm (square) / 330 x 330 mm (rectangular)
– Cut at 45°: Approximately 270 mm (round) / 270 x 270 mm (square) / 270 x 270 mm (rectangular)
– Tape Speed: Adjustable between 20 and 100 m/min.
– Tape Dimensions: Approximately 4100 x 34 x 1.1 mm.
– Main Motor: Approximately 3.0 kW.
Approximate dimensions: 2000 x 1700 x 1800 mm
Weight: 1500 kg
Additional mandatory dismantling & loading on truck cost of: 200€
Location
- 2430-000 Marinha Grande
Dates
Inspection
Visits are only possible after prior registration at carrico@netbid.com.
Pickup
05. Jan 2026 - 30. Jan 2026
Collection is only possible after prior registration at carrico@netbid.com.
