Oven Riedhammer TP12,75/2X20/15-E-145AUCTION#19683-172

Electrically heated two-track tunnel furnace (continuous-flow furnace) for debinding and sintering PTC ceramics, Order No. RME-21-002610, year of manufacture 2022; furnace length 12.75 m; usable width 2 x 200 mm, usable height 150 mm; max. temperature for debinding 650 °C, for sintering 1450 °C; Max. heating capacity 360 kW; Kanthal wire heating and SiC heating elements; 19 control groups; conveyor plates 202 x 202 mm, 126 in the furnace; conveyor speed 126–450 mm/h; Furnace cycle time 9–31.7 h; measurement and control system 659 kVA, 400 V, 50 Hz, backup fuse 3 x 400 A; 19 load transformers; noise level < 80 dB(A).
